FEATURES
>Wide Working Voltage
Working voltage from 9-90VDC finds no limitation on different vehicles’ power supply.
>Light and compact
In spite of light in weight (38 grams), every necessary function is fully equipped.
>Built-in Battery
V-5’s built-in battery supports standby time up to 60 hours. In case of power supply failure, the battery can act as backup for around three hours to do trouble-shooting.
>High Sensitive GPS Chipset
Latest MTK high sensitive GPS chipset with built-in antennahelps shorten TTFF (Time to first fix) and pinpoint locations in a more accurate and rapid way.
>ACC Detection
Assisted by ACC signal detection, you are kept informed of your car’s ignition status change.
>Driving behavior Analysis
Harsh Acceleration, Harsh Brake, Sharp turn alarm.
| GSM Specification | |
| GSM frequency | 850/900/1800/1900 MHz |
| GPRS | Class 12, TCP/IP |
| Memory | 32+32Mb |
| Phrase error | RMSPE<5,PPE<20 |
| Max output | GSM850/GSM900:33±3dBm |
| GPS Specification | |
| GPS chipset | MTK high sensitivity chip |
| Frequency | L1,1575.42MHz C/A code |
| GPS channel | 66 |
| Location accuracy | <10 meters |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start≤1sec Avg. cold start≤35sec |
