FEATURES
9-90V Operating Voltage
9-90V Operating Voltage
Wide operating voltage range is suitable for a huge variety of vehicles, including industrial equipment, scooters, golf carts, and more.
Vehicle Battery Protection
Optimized battery protection prevents vehicle batteries from draining out or damage.
Ignition Detection
Constantly detect the ACC/ignition status of the vehicle.
IPX5 Water Resistance
Rugged design ensures continued optimal performance, even in the toughest conditions.
Compact Size
Ideal for the installation in a small space to maximize unnoticeability.
Multiple Alerts
Instant alerts for atypical events such as impounding, geo-fence entry/exit, abnormal vibration, speeding, etc.
SPECIFICATIONS
| GNSS | |
| Positioning system | GPS+BDS+LBS |
| Positioning accuracy | ＜2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ≤1sec Avg. cold start ≤32sec |
| Cellular | |
| Communication network | GSM |
| Frequency | Quad-band 850/900/1800/1900 MHz |
| Power | |
| Battery | 100mAh/3.7V industrial-grade Li-Polymer battery |
| Input voltage | 9-90VDC |
| Physical specification | |
| Dimensions | 73.8 × 25.9 × 12.2mm |
| Weight | 26.6g |
| Feature | |
| Sensors | Accelerometer |
| Ignition detection | ACC Detection |
| Scenarios | Vehicle movement alert, Over-speed alert, Geo-fence, Vehicle battery detection, Power supply disconnection |
| Operating environment | |
| Operating temperature | -20°C to 70°C |
| IP rating | IPX5 |
APPLICATIONS
